Technical data

• Model: AU-H151CS
• Compressor Model: H151CS
• Pression/temperature: MHBP
• Refrigerant Gas: R134a / R407F / R407A / R-404A /R-507
• Compressor Type: Semihermetic
• Voltage: 230/380 V
• Current Type: Three-Phase
• Frequency: 50 Hz
• Electric Current: 5.9/3.4 A
• Displacement: 7.5 m³/h
• Dimensions (LxWxh): 590x710x505 mm
• Power Fan: 165 W
• Fan Diameter: 350 mm
• Room Temperature: 27 °C
• Cooling Cap. -20°C: 1264 Kcal/h
• Cooling Cap. -15°C: 1642 Kcal/h
• Cooling Cap. -10°C: 2098 Kcal/h
• Cooling Cap. -5°C: 2605 Kcal/h
• Cooling Cap. 0°C: 3190 Kcal/h
• Cooling Cap. 5°C: 3826 Kcal/h
• Cooling Cap. 10°C: 4523 Kcal/h

Extra data

To view capacity data for gases other than R134a, check the attached pdf
on the website
