38009 - Fan HRT/4-560/35 Bpn 230/400V 50/60Hz (SB)
- Eunasa code: 38009
- Range: Refrigeration
- Machine type: Different Machines
- Product type: Fan
- Product subtype: Outer Rotor Fan
- Brand: Soler & Palau
- Original
- Quantity/Packaging: 1
Technical data
- Model: HRT/4-560/35 BPN
- Current Type: Three-Phase
- Voltage: 400 V
- Power: 960/620 W
- Electric Current: 1.92/0.62 A
- Speed: 1405/1140 rpm
- Air Flow Direction: Suction Blower
- Blades Num.: 5
- Blade Diameter (Ø1): 552 mm
- Minimun Tº: -40 °C
- Maximum Tº: 50 °C
- Protection: IP54
- Displacement: 12750/10250 m³/h
- Noise Level: 80/74 dB
- Frequency: 50 Hz
- Diameter (Ø):: 706 mm
- Width 1 (W1):: 89 mm
- Width 2 (W2): 53.5 mm
Extra data
Diameter (Ø): 565 mm
Diameter (Ø1): 518 mm
Width (W): 168.5 mm
Width (W1): 142.5 mm
Width (W2): 37 mm
Valid for (brand and model)
- Brand
- Model
Soler & Palau
