Technical data

• Voltage: 230 V
• Voltage Type: AC
• Frequency: 50 Hz
• Dimensions (LxWxh): 460x300x460 mm
• Power: 0.55 kW
• Speed: 2900 rpm
• Noise Level: 73 dB
• Displacement: 4690 m³/h
• Air Flow Direction: Suction Blower
• Electric Current: 3.7 A

Extra data

Material: Galvanized steel sheet covered with epoxy paint
Propeller: Polyamide reinforced with fibreglass
Maximum working T°: 50°C

Capacitor: 20µF - 450V
Standard asynchronous squirrel-cage motor
Protection: IP55
Insulation: Class F

- Designed for wall assembly
