Technical data

• Voltage: 230 V
• Frequency: 50/60 Hz
• Speed (Max/min): 2545/1975 rpm
• Electric C.(Max/min): 1.41/0.93 A
• Inlet Power(Max/min): 313/213 W
• Flow (Max/min): 1950/1530 m³/h
• Noise Level(Max/min): 40/36 db
• Diameter (Ø):: 313 mm
• Length (L):: 780 mm
• Width (W): 432/520 mm
• Height (h): 434 mm
• Voltage Type: AC

Extra data

2-speed ball bearing motor
Protection: IPX4
Working T°: -10°C to 60°C

- Sheet steel exterior
- Thermally and acoustically insulated with rock wool
- Perforated interior to facilitate noise absorption
- External terminal box
- Anti-corrosion finish in grey polymeric coating
