Technical data

• Switching Capacity: 16 A
• No. Poles: 1 Pole
• Function: NO
• Maximum Tº: 210 °C
• Tº Range: 210 °C
• Sensor Diameter(snØ): 6 mm
• Sensor Lenght (snL): 77 mm
• Capillary Lenght(cL): 870 mm
• Shaft Diameter (shØ): 6X4.6 mm
• Shaft Lenght (shL): 23 mm
• Connection Type (1): Faston Term. 6.3mm

Extra data

Temperature max: 190 °C
Range of temperature: 60-190 °C
Number of poles: 1
Function: 1NO
Switching capacity: 16 A
Probe diameter (Ø): 6 mm
Probe length: 77 mm
Capillary pipe length: 870 mm
Shaft diameter (Ø): 6/4.6 mm
Shaft length: 23 mm
Shaft position: left
Rotation angle: 270 °
