46768 - Rotary Hermetic Compressor CTHU33W 50Hz

  • Eunasa code: 46768
  • Range: Hvac
  • Machine type: Air Conditioner
  • Product type: Compressor
  • Product subtype: Rotary Hermetic Compressor
  • Brand: Hitachi
  • Original
  • Quantity/Packaging: 1

Technical data

  • Model: CTHU33W
  • Refrigerant Gas: R-407C
  • Pression/temperature: MHBP
  • Power: 2 1/4 HP
  • Voltage: 230 V
  • Current Type: Single-Phase
  • Frequency: 50 Hz
  • Compressor Type: Rotary Hermetic
  • Displacement: 39 cm³
  • Electric Current: 13.1 A
  • Speed: 2900 rpm
  • Heat Pump: Yes
  • Type Engine Cooling: Wind Type
  • Max. Hounsing Temp.: 99 °C
  • Max.Coil Temperature: 100-127 °C
  • Coil Resistance: 1.18/2.71 Ohms
  • Aspiration Pipe Con.: 1/2 "
  • Dischargue Pipe Con.: 3/8 "
  • T° Condensation: 54.4 °C
  • Cooling Cap. 7.2°C: 5730 Kcal/h
  • Test Type: Ashare 46

Extra data

Width (W): 139.1mm
Height (h): 372.7mm

Valid for (brand and model)

  • Brand
  • Model
  • Hitachi
