Technical data

• Power: 7200 W
• Voltage: 230 V
• Diameter 1(Ø1): 230 mm
• Diameter 2 (Ø2): 220 mm
• Length (L):: 275 mm
• Length 1 (L1): 33 mm
• Width 1 (W1):: 102 mm
• Height (h): 82 mm
• Height 1 (h1): 7 mm
• Height 2 (h2): 75 mm
• Pipe Diameter (pØ): 6.3 mm
• Fastening Type: Rectangular Flange
• Flange Length (FL): 140 mm
• Flange Width (FW): 22 mm
• Dist. Between Holes: 125 mm
• Type Of Use: Dry
• Connection Type (1): Thread M4
