Technical data

• Power: 2500 W
• Voltage: 230 V
• Diameter 1(Ø1): 201 mm
• Diameter 2 (Ø2): 188 mm
• Length (L):: 206 mm
• Length 1 (L1): 12 mm
• Width 1 (W1):: 31 mm
• Height (h): 35 mm
• Height 1 (h1): 11 mm
• Height 2 (h2): 24 mm
• Pipe Diameter (pØ): 6.2 mm
• Fastening Type: Rectangular Flange
• Flange Length (FL): 100 mm
• Flange Width (FW): 22 mm
• Dist. Between Holes: 86 mm
• Type Of Use: Dry
• Connection Type (1): Faston Term. 6.3mm
• Diameter (Ø):: 200 mm
