Technical data

• Application H.Elemen: Boiler
• Num. Groups: 4 Groups
• Power: 5000 W
• Voltage: 230 V
• Length (L):: 650 mm
• Length 1 (L1): 60 mm
• Width (W): 25.5 mm
• Height (h): 45 mm
• Height 1 (h1): 18 mm
• Height 2 (h2): 27 mm
• Diameter (Ø):: 41 mm
• Pipe Diameter (pØ): 8 mm
• Fastening Type: 2 Holes Flange
• Flange Length (FL): 95 mm
• Flange Width (FW): 60 mm
• Num.Cases: 1
• Case Diameter (CØ): 8 mm
• Case Length: 180 mm
• Type Of Use: Immersion
• Connection Type (1): Thread M6
