Technical data

• Maximum Tº: 110 °C
• Outlet Connec.(ouC): 3/8" M
• Thermocouple C(thcC): M8x1
• Pilot Burner C.(pbC): 1/8"
• Sensor Diameter(snØ): 7 mm
• Sensor Lenght (snL): 150 mm
• Capillary Lenght(cL): 1000 mm
• Shaft Diameter (shØ): 8X6.5 mm
• Shaft Lenght (shL): 33 mm
• Pipe Clamp Inlet Con: 21 mm
• Inlet Connection(iC): Ø21 FLANGE
• Injector Diameter: 0.35 mm

Extra data

Thermostatic gas tap
Shaft diameter(Ø): 8x6.5mm
Length shaft (L): 33mm
Thermocouple: M8x1
Gas inlet: Pipe clamp
Gas outlet : 3/8"
Shaft knob position: 12mm
Bypass nozzle diameter(Ø): 0.35mm
Flat part: Right
Diameter bulb (Ø): 7mm
Length bulb (L1): 150mm
Length capillary (L2): 1000mm
Max T°: 110°C
Pilot burner connection: 1/8"
